Advanced Ceramic Products at a Glance(Classified by method for formation/application)

Shape Forming Appearance Intended Application Raw Materials Finished Products
Cold Isostatic Press (Rubber Press) Non-porous (Tight)
  • Sagger
  • Setter
  • Crucible
  • Wear resistant parts
  • Shock resistant parts
  • Heat-resistant impact parts
  • Pot mill container
  • Stirring blade
  • Ring
  • Nozzle
  • Ferrules
Alumina Alumina CIP (Rubber Press) Products
Magnesia Magnesia CIP (Rubber Press) Products
Zirconia Yttria Stabilized Zirconia CIP (Rubber Press) Products
Aluminum Titanate Aluminum Titanate CIP (Rubber Press) Products
Injection Molding Non-porous (Tight)
  • Crucible for Chemistry Laboratory
Alumina Alumina Injection Molding Products(Crucible for Chemistry Laboratory )
  • Refractory Ceramic Sagger
Non-porous & Heat-Resistant Alumina Injection Molding Products(Refractory Ceramic Sagger)
Press Porous/Non-porous (Tight)
  • Refractory
  • Crucible
  • Sagger
  • Parts for Sintering Apparatus
Alumina Press Forming Products(Refractory / Crucible / Sagger / Parts for Sintering Apparatus )
Magnesia
Zirconia
Mullite
Extrusion Porous
  • Ceramic Insulators for Heaters
Alumina Alumina / Magnesia / Silica Extrusion Molding Products(Ceramic Insulators for Heaters)
Silica
Non-porous (Tight)
  • Thermocouple Protection Tube
Various Materials Extrusion Molding Products(Thermocouple Protection Tube)

Advanced Ceramic Products at a Glance(Classified by materials / products)

Alumina ( Al2O3 ) Crucible, Plate (Setter / Lid) and Sagger (Boat / Rod)

Our Products
  • FA-PS92 (Alumina Al2O3 92% Non-porous Press Forming Products)
  • FA-PS96 (Alumina Al2O3 96% Non-porous CIP Products)
  • FA-PS99 (Alumina Al2O3 99.5% Non-porous CIP Products)
  • FA-PS999 (High-purity Alumina Al2O3 99.9% Non-porous CIP Products)
Specification and Dimension of Our Alumina CIP Products
  • FA96 (Alumina Al2O3 96% Non-porous Injection Molding Products)
  • FA99X (Alumina Al2O3 99.7% Non-porous Injection Molding Products)
Specification and Dimension of Our Alumina Injection Molding Products (Crucible for Chemistry Laboratory )
Features
The most popular ceramics achieving higher than average level of resistance to heat, chemical attack, thermal shock (spalling), intensity and wear, in addition to being of low cost.
Intended Application
  • High heat resistant parts
  • High electrical insulator parts
  • Wear resistant parts
  • Chemical attack resistant containers
  • High temperature crucibles
  • High intensity tiles
  • High temperature tubes
  • Protection tubes / Tammann tubes
  • Ferrules / Manifold tubes
Alumina CIP product (crucible)
Alumina cast product (sagger)

Magnesia (MgO) Crucible, Plate (Setter / Lid) and Sagger (Boat / Rod)

Our Products
  • FM-PS (Magnesia MgO 98.5% Non-porous)
  • FM-PSC (Magnesia MgO 99.0% Non-porous)
Specification and Dimension of Our Magnesia CIP (Rubber Press) Products
Features
Having high melting point, large thermal conductivity, and good electrical insulation in high temperature.
Showing excellent resistance to chemical attack, especially wet corrosion resistance against basic materials such as slag or lead, magnesia products are widely used as metal melting crucibles or as temporary ovens in the semiconductor sintering process.
Intended Application
  • Ultra-high temperature insulation parts
  • Corrosion resistant crucibles
  • Sintering closed containers
  • Chemical attack resistant containers
  • Protection tubes / Tammann tubes
  • High temperature industrial heaters
  • Battery materials
マグネシアCIP品(ルツボ
マグネシアCIP品(サヤ・ワク)

Zirconia (ZrO2) Crucible, Plate (Setter / Lid), Sagger (Boat / Rod) and Ring

Our Products
  • FZ-PS3Y (3mol Yttria Partially Stabilized Zirconia Non-porous)
  • FZ-PS8Y (8mol Yttria Fully Stabilized Zirconia Non-porous)
Specification and Dimension of Our Yttria Stabilized Zirconia CIP (Rubber Press) Products
Features
Being of high level of intensity and fracture toughness, the zirconia products are the most popular materials for wear resistant or shock resistant parts.
Having unique features which differ from that of alumina in response to metals.
Intended Application
  • Wear resistant parts(Nozzle, Ring and Bearing)
  • Parts with characteristic feature of high-intensity and fracture-toughness(Shafts, etc.)
  • Corrosion resistant setter
  • Zirconia pot mill
ジルコニアCIP品(特殊形状)

Aluminum Titanate (TiO2・Al2O3) Crucible, Plate (Setter / Lid) and Sagger (Boat / Rod)

Our Products
  • FTA-PS (Aluminum Titanate TiO2・Al2O3 Non-porous CIP Products)
Aluminum Titanate CIP (Rubber Press) Products
Features
Their coefficient of thermal expansion being nearly zero, excellent in thermal shock resistance.
Will not crack even when heated to 1,000 degrees Celsius and subsequently thrown into water.
(Sample size: 20x25x100 )
In metal dissolution, show excellent non-wetting behavior in contact with fused aluminum and gold.
Intended Application
  • Metal melting crucibles
  • Setters
  • Sintering container(Battery materials / Electronic parts)
チタン酸アルミCIP品(ラドル・焼成治具)

Ceramic Insulator/Pipe Insulation (MgO / Al2O3 / SiO2 / Mullite)・Thermocouple Protection Tube (MgO / Al2O3 / Mullite)

Our Products
  • AA-75 (Alumina Al2O3 75% Porous)
  • MM-50 (Magnesia MgO 50% Porous)
  • MM-75 (Magnesia MgO 75% Porous)
  • MM-99 (Magnesia MgO 90% Porous)
  • SS-99 (Silica SiO2 99% Porous)
Alumina / Magnesia / Silica Extrusion Molding Products(Ceramic Insulators for Heaters) Features
Features
Having a high feasibility of mass production of the pipe insulators, the extrusion method will attain a low cost manufacturing.
※ Thermocouple Protection Tube available (Alumina / Mullite / Magnesia)
Intended Application
  • For electronic tubes: Ceramic Insulators, Spacers, Bases
  • For communicator devices: Ceramic Insulators
  • For circuit parts: Plates, Terminals, Supporters, Bobbins
  • For heat resistant parts: Jigs
  • For thermocouple
アルミナ押出品(ヒータ碍子) (3)
マグネシア押出品(1孔チューブ)
